Chassis: Self-supporting anti-corrosion Aluminum structure
Axles: twin 9000 Kg capacity: 1st self-steering and liftable, 2nd and 3rd fixed, 4th liftable
Brakes: drum Ø 16½ x 7” (420x180 mm) and brake linings asbestos free
Braking system: pneumatic with 2 lines according to North American standard with 4 channel ABS and RSS
Parking Brakes: spring brakes with pneumatic controls
Suspensions: pneumatic type with rising-lowering valve
Wheels: disc 22.5 x 8.25 and M spigot
Tires: 255/70R22.5 twin
King Pin: 2" demountable from below
Landing legs: two speed with rocking feet
Body: box unit for livestock 2+2, 2+3, 3+3, 3+4 or 4+5 loading decks with hydraulic controls, raising lowering roof on lower part and on goose neck, side doors, wide tool boxes under body to store partition gates, internal and external working lights
Rear door: roller shutter door hydraulically controlled
Loading deck: low bed height = 40” (1.00 m), internal working height = 122” (3.10 m)
Electrohydraulic system: independent battery operated electro-hydraulic system completed with automatic safety device in accordance with Machines Directive and Work Safety Institute (approval TUV n° 24 03 9761 002)
Partition gates: in aluminum or in zinc-coated steel with over flap for larger animals
Side windows: closed by sliding panels
